SILVER SERIES

Specifications Technical Data

Length	48.03"	Width	7.09"
Thickness	5mm	Wear Layer	12mil
Finishing	Wood Emboss	Edge Description	Micro Bevel
Sqft/Box	23.64	lb/Box	40.0
Box/Plt	55	Sqft/Plt	1300
lb/Plt	2230	Plt/FTL	19

Floorscore Certification	SCS-EC10.3-2014v3.0	Refer to Standards	Pass
Greenguard Gold Certification	(CDPH) Standard Method V1.2-2017	Refer to Standards	Pass
CE Certification	EN14041	Refer to Standards	Pass
Fire resistance	EN 9239-1 EN ISO11925-2 EN 13501-1	Critical Flux^f≥8.0kW/m² Fs≤150mm within 20s Smoke≤750% minutes	B_fl-S1
Slip resistance	EN13893	N/A	Class DS
Slip resistance (oil-wet ramp test)	DIN 51130:2014-02	N/A	Critical angle of inclination: 14.8°Classification: R10 Pass
Phthalate tests (DBP/BBP/DEHP/DINP/ DNOP/DIDP)	EN 14372:2004	N/A	Free
Dimension stability	ASTM F2199-09(R2014)	≦0.25%	Manufacturing direction:-0.046% Across-manufacturing direction:-0.009%
Determination of dimensional stability and curling after exposure to heat	ISO 23999:2012	≤0.25% The curling ≤ 2mm	MD:-0.05% AMD: 0% 0mm
Seam strength	EN 684:1995	N/A	Ave.:360N/50mm Pass Min.:330N/50mm
Residual indentation (%)	ASTM F1700-13a & ASTM F1914-07(2011)	Average value≦8 Individual value≦10	0.4 Pass
Determination of Indentation and Residual Indentation	ISO 24343-1:2012	N/A	0mm Pass
Resistance to chemicals	ASTM F1700-13a & ASTM F925-13	No more than a slight change in surface dulling,surface attack,or staining	No change in surface dulling,surface attack,or staining was detected
Heat stability	ASTM F1514-03(R2013)	△E*_ab< 8	△E*_ab=0.67 Pass
Static loading	ASTM F970-17	N/A	0.04mm Pass
Soluble heavy metal contents test	ASTM F963-16(Clause 8.3)	N/A	Free
Large ball impact resistance	NALFA/ANSI LF-01-2011	N/A	No cracks or fractures occurred at the height of 2500mm
Static Electrical Propensity	EN 1815:2016 method A	≦2kV	0.2kV
Sound Transmission Class with 1mm Padding	ASTM E90-2009(R2016) ASTM E413-10	N/A	STC=52
Formaldehyde	ISO 17226-1:2008	N/A	Free
Surface Bond	NALFA/ANSI LF-01-2011	N/A	1.14MPa Pass
Resilient floor covering Determination of peel resistance	EN ISO 24345:2012	≥54N/50mm	Longitudinal direction:95N/50mm Cross direction:95N/50mm
Thermal conductivity	EN 12667:2001	N/A	0.154 W/(m.K)
Thermal Resistance	EN 12667:2001	N/A	0.033(m².K)/W
Colour Fastness	EN ISO 105-B02:2014	N/A	Grade 6
Curling	ISO 23999:2008	N/A	Average: 0.5mm Pass
Residual indentation	ISO 24343-1:2007	N/A	Average: 0.02mm Pass
Locking strength	ISO 10582:2017 Annex D	Class 32, type I:≥1.5kN/m	Long side(X): 7.6 kN/m Short side(Y): 6.3 kN/m Pass
Resistance to staining	ISO 26987:2008	N/A	Index 0: Not affected Pass
Resistance to bacteria	ISO 846-1997 Method C	N/A	Assessment of bacteria growth: 0 Pass
Abrasion resistance (0.3mm wearlayer)	EN13329:2016+A1:2017	≥2000 cycles	2400 cycles Abrasion Class: >AC3
